RR RACE
4T 350

My 27
My 26

The RR Race 350 4T is the perfect choice for anyone looking for a four-stroke ready for competition with a sharp chassis and power that’s always under control. It’s the most manoeuvrable model in the 4T range, putting everyone at ease, from amateur riders to the most experienced.

Find your dealer download the brochure

349 cc

Displacement

88 x 57,4 mm

Bore x stroke

950 mm

Seat height

107,5 kg

Dry weight

MAIN FEATURES

ELECTRONICS

LAUNCH CONTROL AND QUICK SHIFT

Making their debut on the 4-stroke range are Launch Control (LC), for perfect starts with zero wheel spin, and Quick Shift (QS), for changing gears without lifting off the throttle. The controls are mounted on a new button panel integrated into the redesigned handlebar guard, alongside the Map Switch and Traction Control.

SUSPENSION

KYB SUSPENSION KIT WITH New SETTINGS

The 48 mm KYB AOS closed-cartridge front fork and the KYB C46 RCU monoshock feature new hydraulic settings developed in competition. The kit ensures maximum shock absorption, traction and handling responsiveness even in the most extreme conditions.

DESIGN

LED HEADLAMP AND NEW HEADLIGHT MASK

Design and functionality come together in the new headlight mask with integrated headlamp, which features a powerful, latest-generation LED headlamp. It provides a more powerful beam and lower power consumption, which is better for the battery.

NEW TRAILTECH SPEEDOMETER

The new Trailtech dashboard makes its debut: it is larger, more robust and easier to read even in the harshest conditions. It is paired with the new wheel reed sensor for high-precision speed readings.

REINFORCED TRANSMISSION PROTECTION

The MY27 introduces the new chain guard with a reinforced structure to withstand mud and impacts, and the new front sprocket guard, redesigned to offer wider, more robust coverage that complies with competition regulations.

SOFT GRIPS

The new soft-compound grips absorb vibrations transmitted from the handlebars, reducing pressure on the forearms to ensure a secure grip and prolonged physical endurance.

ERGAL FOOTPEGS AND ZF SPROCKETS

Ergal racing footpegs with steel pins for maximum grip and to facilitate foot movement. ZF Sprocket rear sprocket with an aluminium core and steel teeth for the perfect blend of lightness and durability.

RACING SEAT AND BI-COMPONENT HANDGUARDS

Dedicated racing seat with non-slip covering and a document pocket. Reinforced handguards made from bi-component material to give a racing look and maximum durability in intense off-road conditions.

RACING LOOK

Red anodised details (quick-release wheel spindle, chain tensioner bolt, oil caps) and official racing graphics complete an aggressive and unmistakable aesthetic on the race track.

Ideal balance between lightness and traction

The RR Race 350 4T combines responsiveness, lightness and the brilliance of an extremely versatile engine. With the MY27 technological innovations, including Launch Control, Quick Shift and race-tuned KYB suspension, rideability is taken to a whole new level. The race-ready set-up and high-spec components complete the perfect package to dominate in competitive enduro.

Do you need further information?
manual brochure Tech Specs

CHASSIS

FRAME

Molybdenum steel with double cradle split above the exhaust port

WHEELBASE

1476 mm

MAX LENGTH

2180 mm

MAX WIDTH

830 mm

MAX HEIGHT

1275 mm

SEAT HEIGHT

950 mm

GROUND CLEARANCE

355 mm

FOOTREST HEIGHT

427 mm

DRY WEIGHT

107,5 kg (front 52,7 kg; rear 54,8 kg)

FUEL TANK CAPACITY

9,0 l

reserve

2,3 l

COOLING SYSTEM CAPACITY

1,4 l

FRONT SUSPENSION

KYB Sealed cartridge USD front fork ( ø 48 mm )

REAR SUSPENSION

KYB Monoshock with progressive compound lever

SHOCK ABSORBER STROKE

130 mm

FRONT WHEEL TRAVEL

300 mm

rear WHEEL TRAVEL

287 mm

FRONT BRAKE

Wave disc Ø260 mm and double-piston floating caliper

rear BRAKE

Wave disc Ø240 mm and single-piston floating caliper

FRONT RIM

21 x 1,6 – 36 holes

rear RIM

18 x 2,15 – 36 holes

FRONT TYRE

90/90 – 21

REAR TYRE

140/80 -18

ENGINE

TYPE

Single cylinder, 4-stroke, liquid-cooled

BORE

88 mm

STROKE

57,4 mm

DISPLACEMENT

349,1 cc

COMPRESSION RATIO

13,19:1

VALVE TRAIN

Dohc finger follower / 4 titanium valve

STARTER

Electric starter

acg

AC – CDI Kokusan

spark plug

NGK LKAR 8A-9

lubrication

2 oil pumps

fuel system

Elldor dual electronic injection

throttle body

Ø 42 mm – Synerject

clutch

Wet multi-disc clutch

PRIMARY DRIVE

Z.28/76

TRANSMISSION

6 gears

final transmission

Chain

ENGINE OIL

SAE 10W/50 0,8 l. + SAE 10W/40 0,8 l.

CONSUMPTION l/100km

3,4

POLLUTION Co2 [g/km]

80
