XTRAINER
2T 200

My27

The new Beta XTrainer 200 2T introduces a whole new dimension to the world of off-road riding. Born from a brand-new design, this model stands out for its extraordinarily docile character, extreme lightness and disarming agility, offering a unique package on the market that combines pure fun with maximum adaptability. Designed to enhance the skills of riders of all levels, the XTrainer 200 is the ideal solution for less experienced riders thanks to its accessibility, yet it also thrills even the most advanced riders.

find your dealer download the brochure

190,2 cc

Displacement

62 x 63 mm

Bore x stroke

910 mm

Seat height

97,5 kg

Dry weight

Main Features

ENGINE


The new 200 CC heart

The XTrainer 200 2-stroke engine is the result of a completely new design, developed to enhance control and rideability at low revs without compromising on pure performance. Thanks to the cylinder, engine head and piston – developed with dedicated timing – combustion chamber filling is optimised to ensure an increase in torque just above idle, a smooth response to throttle input and a linear power delivery that eliminates physical strain during technical riding.

NEW REAR BRAKE DISC

The Nissin braking system features a brand-new solid rear brake disk with a wavy profile. This solution ensures significantly more progressive and modulated braking, a crucial advantage for maintaining total control on the slowest, steepest and most technical descents.

NEW GRAPHICS

The completely revamped graphics introduce a brand-new, aggressive combination of red plastics and a black-painted frame, redefining the aesthetic character of the range.

COOLING FAN

Fitted as standard to ensure perfect thermal balance. It allows the engine to remain at the optimum operating temperature at all times, even during the slowest trial sections with poor airflow.

REINFORCED CHAIN GUIDE

Completely redesigned to be more robust and resistant to impacts from stones, mud and deep ruts. Its reinforced structure better absorbs stress, protects the swingarm and minimises the risk of the chain jumping off.

LOW-LOAD CLUTCH SPRINGS

The use of softer clutch springs drastically reduces the effort required at the lever. This feature enhances controllability and riding enjoyment, a key factor for navigating slow sections and trial-style obstacles with precision.

Perfect balance between traction and agility

The new engine is integrated into an updated frame with dedicated connections to ensure correct weight distribution and maximum ease of control. For the rear wheel, Beta’s engineers have chosen an 18 x 1.85 rim with a 140/80 tyre, the ideal compromise for maximising traction and steering response on technical terrain.

Do you need further information?
manual brochure Tech Specs

CHASSIS

Frame

Perimetric frame in molybdenum steel with double cradle split above the exhaust port

Wheelbase

1467 mm

Max length

2157 mm

Max width

802 mm

Max height

1245 mm

Seat height

910 mm

Ground clearance

320 mm

Footrest height

390 mm

Dry weight

97,5 kg (front 47 kg; rear 50,5 kg)

Fuel tank capacity

8,5 l

Reserve

1,5 l

Cooling system capacity

1,3 l

Oil tank capacity

650cc

Front suspension

Hydraulic USD fork with ø 43 mm shaft

Rear suspension

Monoshock with progressive compound lever

Shock absorber stroke

110 mm

Front wheel travel

270 mm

Rear wheel travel

270 mm

Front brake

Wave disc ø260 mm and double-piston floating caliper

rear brake

Wave disc ø240 mm and single-piston floating caliper

Front rim

21 x 1,6 – 36 holes

rear rim

18 x 1,85 – 36 holes

Front tyre

90/90 – 21

Rear tyre

140/80 -18

ENGINE

Type

Single cylinder, 2-stroke, liquid-cooled

Bore

62 mm

Stroke

63 mm

Displacement

190,2 cc

Compression ratio

14,35:1

Exhaust Valve

BPV System

Starter

Electric starter

Ignition

AC – digital CDI with oil pump controller

Spark plug

NGK CMR7H

Induction system

Induction reed

Lubrication

Mixing with electronic pump

Carburettor

Keihin PWK 36

Clutch

Wet multi-disc clutch

Primary drive

Z.25/73

Transmission

6 gears

Final transmission

Chain

Engine oil

SAE 10W/40

Consumption l/100 km

2,5

Pollution Co2 [g/km]

59
